Littelfuse SP3213 0.09pF 12kV Bidirectional Discrete TVS Diode Arrays offer ultra-low capacitance ESD protection for electronic equipment. The bidirectional arrays have a typical capacitance of 0.09pF to ensure excellent signal integrity on the most challenging consumer electronics interfaces, including USB 3.1, HDMI 2.0, DisplayPort, Thunderbolt, and V-by-One®. Littelfuse SP3213 TVS Diodes can safely absorb repetitive ESD strikes at ±12kV (contact discharge, IEC 61000-4-2) without performance degradation and safely dissipate 2A of 8/20μs surge current (IEC 61000-4-5 2nd edition).
Features
ESD, IEC 61000-4-2, ±12kV contact, ±18kV air
EFT, IEC 61000-4-4, 40A (5/50ns)
Lightning, 2A (8/20 as defined in IEC 61000-4-5 2nd edition)
0.02μA (typical) at 5V low leakage current
Space efficient 0201 footprint
AEC-Q101 qualified
Halogen-free, lead-free, and RoHS compliant
Moisture Sensitivity Level: MSL -1
Applications
Ultra-high-speed data lines
USB 3.1, 3.0, 2.0
HDMI 2.0, 1.4a, 1.3
DisplayPort™
Thunderbolt
LVDS interfaces
Consumer, mobile, and portable electronics
Tablet PC and external storage with high-speed interfaces
